SUN HYDRAULICS
SXEAKCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXEAKCN (Material Number: SXEAKCN) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the inlet port 1 pressure surpasses the valve setting. This model is part of Sun Hydraulics' versatile line of 3-port sequence cartridges, which are physically and functionally interchangeable, meaning they share the same flow path and cavity for a given frame size. The SXEAKCN features zero pilot flow; however, port 3 must be connected to maintain a pressure reference in the control chamber, as blocking it may result in valve malfunction due to reciprocating seal weepage. The valve can handle pressures at port 3 up to 5000 psi (350 bar), which directly adds to the valve setting at a 1:1 ratio. This product is particularly suitable for load-holding applications and incorporates Sun's floating style construction, minimizing the risk of internal parts binding from excessive installation torque or machining variations. It has a capacity of 30 gpm (120 L/min) and operates optimally at pressures up to 5000 psi (350 bar). The typical response time for this model is approximately 2 ms, with maximum valve leakage at reseat being about 10 drops/min (0.7 cc/min). For adjustments, the SXEAKCN requires four clockwise turns to increase its setting, with specific torque requirements for installation and adjustment components: valve hex size is 1-1/8 in. (28.6 mm), installation torque ranges from 45-50 lbf-ft (61-68 Nm), adjustment screw internal hex size is 5/32 in. (4 mm), locknut hex size is 9/16 in. (15 mm), and locknut torque ranges from 80-90 lbf-in (9-10 Nm). The model weighs approximately .60 lb (.30 kg) and uses Viton seal kits identified as part number 990202006.
