SUN HYDRAULICS
SXEAKDN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXEAKDN (SXEAKDN) is a direct-acting sequence valve designed to manage secondary circuit flow once the inlet port pressure surpasses the valve setting. This valve controls the pressure at port 1 in relation to the drain port 3, with all three-port sequence cartridges being interchangeable for a given frame size. Despite being a zero pilot flow valve, it requires port 3 to be connected for maintaining pressure reference; blocking this port can lead to malfunction due to seal weepage. The pressure at port 3 directly adds to the valve setting at a 1:1 ratio, with a maximum limit of 5000 psi (350 bar). This valve is particularly suitable for load-holding applications and incorporates Sun's floating style construction, which minimizes binding risks from excessive installation torque or machining variations. The SXEAKDN features a cavity T-2A series with a capacity of up to 30 gpm (120 L/min) and operates under pressures up to 5000 psi (350 bar). It exhibits typical response times of around 2 ms and has minimal leakage upon reseating, capped at 10 drops/min (0.7 cc/min). The adjustment can be fine-tuned with four clockwise turns to increase settings, utilizing an internal hex size of 5/32 inches (4 mm) for precision control. Installation requires specific torques: valve installation torque ranges between 45-50 lbf ft (61-68 Nm), while locknut torque is set between 80-90 lbf in (9-10 Nm). Weighing approximately .60 lb (.30 kg), it also offers compatibility with Viton seal kits for enhanced sealing performance.
