SUN HYDRAULICS
SXEAKWN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXEAKWN (SXEAKWN) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the inlet port pressure surpasses the valve setting. This valve manages pressure at port 1 relative to the drain port 3, ensuring precise control in various applications. All three-port sequence cartridges are interchangeable, maintaining the same flow path and cavity for a given frame size. It's crucial to connect port 3 to maintain a pressure reference in the control chamber, as blocking it can lead to malfunction due to reciprocating seal weepage. The pressure at port 3 directly adds to the valve setting at a 1:1 ratio and must not exceed 5000 psi (350 bar). This model is suitable for load-holding applications and features Sun's floating style construction, which minimizes internal part binding from excessive installation torque or machining variations. With a capacity of 30 gpm (120 L/min) and maximum operating pressure of 5000 psi (350 bar), it offers quick response times typically around 2 ms. The valve's leakage at reseat is minimal, with a maximum of 10 drops/minute (0.7 cc/min). The adjustment mechanism allows for four clockwise turns to increase settings, ensuring flexibility in operation. The SXEAKWN has specific installation requirements: a valve hex size of 1-1/8 inches (28.6 mm), installation torque ranging from 45-50 lbf-ft (61-68 Nm), an adjustment screw internal hex size of 5/32 inches (4 mm), and locknut torque between 80-90 lbf-in (9-10 Nm). Weighing .60 lb (.30 kg), this model includes a Viton seal kit under cartridge number 990202006, providing robust sealing performance for demanding environments.
