SUN HYDRAULICS
U6F

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics U6F (Material Number: U6F) is a robust and versatile line mount manifold designed for hydraulic applications. Featuring a ninety-degree body type, it accommodates efficient fluid routing in compact spaces. This manifold is engineered with a through-hole mounting system, including 22 holes with a diameter of 0.34 inches (8.6 mm), allowing for secure and adaptable installation. It includes one open cavity configured to the T-52A standard, suitable for various cartridge valve integrations. The U6F model supports SAE 12 port sizes, ensuring compatibility with standard hydraulic systems. Constructed from 6061T651 aluminum, this manifold offers excellent corrosion resistance without the need for anodizing, making it durable and reliable in various environments. The choice of material also provides a balance between strength and machinability while maintaining cost-effectiveness. However, users should note that aluminum manifolds like the U6F are not rated for pressures exceeding 3000 psi (210 bar). Applications of the Sun Hydraulics U6F include systems requiring high flow rates where line mounting is essential for spatial efficiency or system design constraints. It is particularly suited to setups where dual path cartridges are used; however, unused ports should be plugged to manage pressure drops effectively. This manifold's design considerations emphasize the importance of understanding system pressure requirements since these affect the overall performance and safety of hydraulic installations using this component. The Sun Hydraulics U6F model provides a reliable solution for integrating complex hydraulic circuits within compact and demanding environments.
