SUN HYDRAULICS
U6G

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics U6G (Material Number: U6G) is a line mount hydraulic manifold designed for high-flow applications. Constructed from 6061T651 aluminum, this manifold features a ninety-degree body type with two mounting holes, each having a diameter of .34 inches (8.6 mm) and through-hole depth. It accommodates open cavities and is compatible with T-52A cavity cartridges. The port size is specified as 3/8 BSPP, ensuring compatibility with standard hydraulic systems. This manifold is engineered to withstand pressures up to 3000 psi (210 bar), making it suitable for various hydraulic applications where robust performance is required. The U6G's design facilitates easy integration into existing systems, providing flexibility in hydraulic circuit configurations. Its aluminum construction offers excellent corrosion resistance, eliminating the need for anodizing while maintaining structural integrity under pressure. This makes it an ideal choice for environments where corrosion could be a concern but where the additional cost and complexity of anodizing are not justified. When using this manifold with FTA or dual path cartridges, it is important to plug unused ports to prevent higher pressure drops and ensure optimal performance. Users should also carefully consider the maximum system pressure in relation to the manifold material, as exceeding recommended pressure limits can compromise safety and functionality. Overall, the Sun Hydraulics U6G manifold provides a reliable solution for managing fluid flow in hydraulic systems, combining durability and ease of use in its design while supporting efficient system operation across various applications.
