SUN HYDRAULICS
U8W
$88.76 USD
- SUN HYDRAULICS
- Material:U8W
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics U8W (Material Number: U8W) is a line mount hydraulic manifold designed to accommodate high flow valves. This model features a common port 1 with coil clearance and includes two open cavities, specifically the 22Cavity T13A configuration, making it suitable for complex hydraulic systems requiring efficient fluid distribution. The manifold is constructed from 6061T651 aluminum, a material known for its strength, corrosion resistance, and availability in various shapes and sizes. It supports SAE 6 port sizes, ensuring compatibility with standard hydraulic fittings. Notably, the manifold is not anodized due to considerations of cost, logistics, consistency in manufacturing processes, and potential impacts on fatigue life. The maximum system pressure should be carefully considered when using this manifold; it is rated for pressures up to 3000 psi (210 bar), as determined by the aluminum construction regardless of port size or type. This product is ideal for applications that require robust performance in demanding environments while maintaining reliability over time.
The Sun Hydraulics U8W (Material Number: U8W) is a line mount hydraulic manifold designed to accommodate high flow valves. This model features a common port 1 with coil clearance and includes two open cavities, specifically the 22Cavity T13A configuration, making it suitable for complex hydraulic systems requiring efficient fluid distribution. The manifold is constructed from 6061T651 aluminum, a material known for its strength, corrosion resistance, and availability in various shapes and sizes. It supports SAE 6 port sizes, ensuring compatibility with standard hydraulic fittings. Notably, the manifold is not anodized due to considerations of cost, logistics, consistency in manufacturing processes, and potential impacts on fatigue life. The maximum system pressure should be carefully considered when using this manifold; it is rated for pressures up to 3000 psi (210 bar), as determined by the aluminum construction regardless of port size or type. This product is ideal for applications that require robust performance in demanding environments while maintaining reliability over time.
| Body Type | Line mountLine mount |
| Body Features | Common port 1 with coil clearanceCommon port 1 with coil clearance |
| Open Cavities | 22 |
| Cavity | T-13A |
| Port Size | SAE 6SAE 6 |
Show FAQ
Additional Resources
- Standard Line Mount Manifolds for High Flow Valves
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Manufacturing Sun Cartridge Cavities
- Fluid and Temperature Recommendations
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
