SUN HYDRAULICS
VFD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VFD (Material Number: VFD) is a versatile line mount manifold designed for hydraulic systems, featuring a 2.00 SAE C62 interface and direct mount body type. It accommodates open cavities with a T19A cavity configuration and includes port sizes of 2 Code 62. Constructed from 6061T651 aluminum, this manifold offers a balance of strength, cost-effectiveness, and corrosion resistance, making it suitable for various hydraulic applications. The decision not to anodize the aluminum enhances its fatigue life by avoiding the brittle surface that anodizing can create, which can lead to fatigue cracks under pressure. This design choice ensures durability and reliability in demanding environments, although it limits the maximum system pressure to 3000 psi (210 bar), as is standard for aluminum manifolds regardless of port size or type. The Sun Hydraulics VFD manifold is engineered to integrate seamlessly with high-flow valves using Sun's cartridge cavities and comes with additional resources like QuickDesign tools for custom schematic design and integrated package solutions.
