SUN HYDRAULICS
VTU
$211.07 USD
- SUN HYDRAULICS
- Material:VTU
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VTU (VTU) is a versatile gasket mount manifold designed for direct mounting with cross pilot features. It includes a mounting hole diameter of 0.34 inches (8.6 mm), a c'bore diameter of 0.53 inches (13.5 mm), and a c'bore depth of 0.25 inches (6.4 mm). The manifold accommodates two mounting holes and two open cavities, specifically designed for the T-21A cavity type. Constructed from 6061-T651 aluminum, this manifold offers excellent corrosion resistance and durability, making it suitable for various hydraulic applications where reliability and longevity are crucial. The VTU model is engineered to handle system pressures up to 3000 psi (210 bar), which should be considered when integrating it into hydraulic systems to ensure compatibility with the intended application pressures. Its design emphasizes ease of installation and maintenance, providing a robust solution for hydraulic systems requiring efficient fluid control in compact spaces. This manifold does not undergo anodization due to the inherent corrosion-resistant properties of its aluminum material, ensuring that it maintains its integrity without additional surface treatments that could affect its fatigue life or introduce inconsistencies in performance. The VTU manifold's construction focuses on providing an efficient plumbing solution without the need for additional wear surfaces, making it an ideal choice for applications where simplicity and reliability are prioritized. Overall, the Sun Hydraulics VTU model is crafted to deliver dependable performance in demanding environments while minimizing maintenance requirements, thanks to its high-quality materials and thoughtful engineering design tailored specifically for hydraulic system integration.
The Sun Hydraulics VTU (VTU) is a versatile gasket mount manifold designed for direct mounting with cross pilot features. It includes a mounting hole diameter of 0.34 inches (8.6 mm), a c'bore diameter of 0.53 inches (13.5 mm), and a c'bore depth of 0.25 inches (6.4 mm). The manifold accommodates two mounting holes and two open cavities, specifically designed for the T-21A cavity type. Constructed from 6061-T651 aluminum, this manifold offers excellent corrosion resistance and durability, making it suitable for various hydraulic applications where reliability and longevity are crucial. The VTU model is engineered to handle system pressures up to 3000 psi (210 bar), which should be considered when integrating it into hydraulic systems to ensure compatibility with the intended application pressures. Its design emphasizes ease of installation and maintenance, providing a robust solution for hydraulic systems requiring efficient fluid control in compact spaces. This manifold does not undergo anodization due to the inherent corrosion-resistant properties of its aluminum material, ensuring that it maintains its integrity without additional surface treatments that could affect its fatigue life or introduce inconsistencies in performance. The VTU manifold's construction focuses on providing an efficient plumbing solution without the need for additional wear surfaces, making it an ideal choice for applications where simplicity and reliability are prioritized. Overall, the Sun Hydraulics VTU model is crafted to deliver dependable performance in demanding environments while minimizing maintenance requirements, thanks to its high-quality materials and thoughtful engineering design tailored specifically for hydraulic system integration.
| Body Type | Gasket mountGasket mount |
| Interface | SunSun |
| Body Features | Direct mount, cross pilotDirect mount, cross pilot |
| Mounting Hole Diameter | .34 in.8.6 mm |
| Mounting Hole C'bore Diameter | .53 in.13,5 mm |
| Mounting Hole C'bore Depth | .25 in.6,4 mm |
| Mounting Hole Quantity | 22 |
| Open Cavities | 22 |
| Cavity | T-21A |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Manufacturing Sun Cartridge Cavities
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
