SUN HYDRAULICS
VVK

$159.24 USD

SUN HYDRAULICS
Material:VVK
Summary:Manifold

Quantity in stock: 0

Note: Sales tax, and shipping will be calculated at checkout.

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VVK (Material Number: VVK) is a versatile hydraulic component designed for efficient signal load sensing applications. This model features a 5-signal load sense shuttle body, supporting effective fluid control in various hydraulic systems. The line mount body type with no specific interface allows for flexible integration into existing setups. It incorporates two mounting holes with a diameter of .41 inches (10.4 mm), accommodating through-hole depth and providing secure attachment with its SAE 6 port size. The manifold includes four open cavities and is compatible with the T-11A cavity type, ensuring compatibility with standard hydraulic components. Constructed from 6061T651 aluminum, the VVK model offers excellent corrosion resistance, making it suitable for demanding environments where durability is essential. Despite its robust construction, this material choice ensures that the product remains relatively lightweight and cost-effective without compromising strength. However, it is crucial to note that the manifold's pressure rating does not exceed 3000 psi (210 bar), as dictated by the properties of aluminum. The Sun Hydraulics VVK model is particularly useful in systems requiring precise load sensing capabilities, providing reliable performance across various applications. Its design facilitates easy installation and maintenance while maintaining high operational efficiency. This product serves as an integral component in enhancing system responsiveness and accuracy within hydraulic circuits.

Description

Body Type	Line mountLine mount
Interface	NoneNone
Body Features	5 signal load sense shuttle body5 signal load sense shuttle body
Mounting Hole Diameter	.41 in.10,4 mm
Mounting Hole Depth	ThroughThrough
Mounting Hole Quantity	22
Open Cavities	44
Cavity	T-11A
Port Size	SAE 6SAE 6

Show FAQ

Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.
Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
