SUN HYDRAULICS
VZN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VZN (Material Number: VZN) is a versatile and robust hydraulic manifold designed for direct mounting with a cross pilot feature. It is engineered to be gasket-mounted with an interface compatible with Sun products. The manifold features a mounting hole diameter of 0.41 inches (10.4 mm) and a mounting hole depth that goes through the entire body, ensuring secure installation. The c'bore diameter measures 0.59 inches (15.0 mm) with a depth of 0.31 inches (8 mm), and there are two mounting holes available to accommodate this setup. The VZN manifold is made from 6061-T651 aluminum, known for its excellent corrosion resistance, making it suitable for various hydraulic applications where durability and longevity are critical. This material choice ensures that the manifold can withstand harsh environments without compromising structural integrity or performance. With open cavities designated as T-22A and equipped with port sizes of 1/2 NPTF, this manifold supports efficient fluid flow management in hydraulic systems. However, it's important to note that aluminum manifolds like the VZN are not rated for pressures exceeding 3000 psi (210 bar), regardless of port type or size specified. This product is ideal for applications requiring reliable hydraulic connections and configurations within the specified pressure limits, providing users with an effective solution for managing fluid dynamics in their systems while maintaining high standards of safety and performance.
