SUN HYDRAULICS
W8G
$39.71 USD
- SUN HYDRAULICS
- Material:W8G
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics W8G (Material Number: W8G) is a line mount manifold designed for hydraulic systems. This product features a ninety-degree, panel mount body type with no specific interface, allowing for versatile integration into various hydraulic setups. It includes four M5x0.8 6H mounting holes with a depth of 9.7 mm and accommodates one open cavity, specifically the T10A cavity. The port size is 3/8 BSPP, making it compatible with standard hydraulic fittings. Constructed from 6061T651 aluminum, the manifold offers excellent corrosion resistance without the need for anodizing, ensuring durability in harsh environments. The material choice also contributes to its relatively strong yet lightweight nature, making it suitable for applications where weight reduction is critical while maintaining structural integrity. This manifold is particularly useful in systems requiring efficient fluid flow management at pressures up to 3000 psi (210 bar), as dictated by its aluminum construction. It serves as an essential component in hydraulic circuits, facilitating the distribution and control of fluid power through various channels within the system. The W8G's design allows it to be used in conjunction with high-flow valves and other hydraulic components that require precise and reliable performance. The Sun Hydraulics W8G manifold's robust design and compatibility with standard cartridge cavities make it an ideal choice for custom integrated packages where space optimization and system efficiency are paramount. Its ease of installation and maintenance further enhance its applicability across diverse hydraulic applications, ensuring long-term performance and reliability under demanding operational conditions.
The Sun Hydraulics W8G (Material Number: W8G) is a line mount manifold designed for hydraulic systems. This product features a ninety-degree, panel mount body type with no specific interface, allowing for versatile integration into various hydraulic setups. It includes four M5x0.8 6H mounting holes with a depth of 9.7 mm and accommodates one open cavity, specifically the T10A cavity. The port size is 3/8 BSPP, making it compatible with standard hydraulic fittings. Constructed from 6061T651 aluminum, the manifold offers excellent corrosion resistance without the need for anodizing, ensuring durability in harsh environments. The material choice also contributes to its relatively strong yet lightweight nature, making it suitable for applications where weight reduction is critical while maintaining structural integrity. This manifold is particularly useful in systems requiring efficient fluid flow management at pressures up to 3000 psi (210 bar), as dictated by its aluminum construction. It serves as an essential component in hydraulic circuits, facilitating the distribution and control of fluid power through various channels within the system. The W8G's design allows it to be used in conjunction with high-flow valves and other hydraulic components that require precise and reliable performance. The Sun Hydraulics W8G manifold's robust design and compatibility with standard cartridge cavities make it an ideal choice for custom integrated packages where space optimization and system efficiency are paramount. Its ease of installation and maintenance further enhance its applicability across diverse hydraulic applications, ensuring long-term performance and reliability under demanding operational conditions.
| Body Type | Line mountLine mount |
| Interface | NoneNone |
| Body Features | Ninety degree, panel mountNinety degree, panel mount |
| Mounting Hole Thread | M5x.08 - 6HM5x.08 - 6H |
| Mounting Hole Depth | .38 in.9,7 mm |
| Mounting Hole Quantity | 44 |
| Open Cavities | 11 |
| Cavity | T-10A |
| Port Size | 3/8" BSPP3/8" BSPP |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Standard Line Mount Manifolds for High Flow Valves
- Manufacturing Sun Cartridge Cavities
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
