SUN HYDRAULICS
WXN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics WXN (Material Number: WXN) is a line mount manifold designed with a ninety-degree body featuring a gauge port. It is constructed from 6061T651 aluminum, known for its excellent corrosion resistance and relatively strong yet cost-effective properties. The manifold is equipped with M10x1.5 6H metric models for mounting hole threads and has a mounting hole depth of 15.7 mm, with two holes available for secure installation. This model is designed to accommodate open cavities in the T18A configuration and features port sizes of 12 Code 61 on both ends, providing reliable connections for hydraulic systems. This manifold is intended for use in hydraulic applications where space optimization and robust performance are critical. Its construction allows it to handle pressures up to 3000 psi (210 bar), making it suitable for various high-flow valve applications. The line mount design facilitates easy integration into existing systems without the need for extensive modifications. Sun Hydraulics' decision not to anodize the aluminum bodies of their manifolds ensures that the natural corrosion resistance of the material is maintained while avoiding potential issues related to fatigue life reduction, increased torque during disassembly, and inspection difficulties associated with anodized surfaces. This makes the WXN manifold an ideal choice for environments where durability and long-term reliability are paramount. Overall, the Sun Hydraulics WXN model offers a practical solution for hydraulic system designers seeking a versatile and dependable manifold capable of supporting demanding operational requirements without compromising on quality or performance.
