SUN HYDRAULICS
X4H

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics X4H (Material Number: X4H) is a meticulously engineered line mount manifold designed for hydraulic systems. This product features a banjo bolt interface with a direct mount body type, ensuring robust and secure connections in high-pressure environments. The banjo bolt installation torque ranges from 170 lb. ft. to 185 lb. ft. (230 Nm to 250 Nm), providing a reliable fit and minimizing the risk of leakage or loosening under operational stresses. The manifold is equipped with one open cavity type T-2A and has a port size of 3/4 BSPP, making it compatible with various hydraulic applications that require precise fluid control and distribution. Constructed from 6061-T651 aluminum, the X4H manifold offers excellent corrosion resistance, making it suitable for use in harsh environments without the need for anodizing. This material choice balances strength and cost-effectiveness while maintaining durability over time. Although the manifold is not anodized, its natural corrosion resistance makes it a reliable component in hydraulic systems where longevity and performance are critical. The X4H manifold's design facilitates easy integration into existing systems, thanks to its standard line mount configuration and compatibility with high flow valves. Its robust construction ensures that it can withstand pressures up to 3000 psi (210 bar), provided that the system's maximum pressure considerations align with these specifications. This makes the Sun Hydraulics X4H an ideal choice for applications requiring dependable fluid management solutions without compromising on performance or safety standards.
