SUN HYDRAULICS
XNOAXXV
$43.78 USD
- SUN HYDRAULICS
- Material:XNOAXXV
- Model:XNOA-XXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XNOAXXV (Material Number: XNOAXXV) is a versatile cavity plug designed for use in both four-port and six-port cavities. When installed in four-port cavities such as T21A, T22A, T23A, and T24A, it maintains connectivity between ports 1 and 2 while effectively blocking ports 3 and 4. In six-port cavities like T61A, T62A, T63A, and T64A, this plug connects ports 1 through 4 while blocking ports 5 and 6. It is engineered to handle a maximum operating pressure of up to 5000 psi (350 bar), ensuring robust performance under demanding conditions. The valve hex size measures at 1-1/8 inches (28.6 mm), with an installation torque range of 45 to 50 lbf-ft (61 to 68 Nm), facilitating secure and reliable installation. The recommended seal kit for this cartridge is Viton: 990022006, which provides excellent sealing capabilities under various operating conditions. This product is particularly suitable for applications requiring precise control over fluid pathways within hydraulic systems.
The Sun Hydraulics XNOAXXV (Material Number: XNOAXXV) is a versatile cavity plug designed for use in both four-port and six-port cavities. When installed in four-port cavities such as T21A, T22A, T23A, and T24A, it maintains connectivity between ports 1 and 2 while effectively blocking ports 3 and 4. In six-port cavities like T61A, T62A, T63A, and T64A, this plug connects ports 1 through 4 while blocking ports 5 and 6. It is engineered to handle a maximum operating pressure of up to 5000 psi (350 bar), ensuring robust performance under demanding conditions. The valve hex size measures at 1-1/8 inches (28.6 mm), with an installation torque range of 45 to 50 lbf-ft (61 to 68 Nm), facilitating secure and reliable installation. The recommended seal kit for this cartridge is Viton: 990022006, which provides excellent sealing capabilities under various operating conditions. This product is particularly suitable for applications requiring precise control over fluid pathways within hydraulic systems.
These cavity plugs can be used for both four-port and six-port cavities. When used in four-port cavities (T-21A, T-22A, T-23A and T-24A), ports 1 and 2 remain connected and ports 3 and 4 are blocked. When used in six-port cavities (T-61A, T-62A, T-63A and T-64A), ports 1, 2, 3 and 4 remain connected and ports 5 and 6 are blocked.
| Cavity | T-22A & T-62A |
| Series | 2 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-022-006 |
