SUN HYDRAULICS
XPOAXXN
$51.23 USD
- SUN HYDRAULICS
- Material:XPOAXXN
- Model:XPOA-XXN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XPOAXXN (Material Number: XPOAXXN) is a versatile cavity plug designed for use in both four-port and six-port cavities. In four-port cavities such as T21A, T22A, T23A, and T24A, this plug effectively connects ports 1 and 2 while blocking ports 3 and 4. For six-port cavities like T61A, T62A, T63A, and T64A, it connects ports 1 through 4 and blocks ports 5 and 6. This product is suitable for applications requiring a maximum operating pressure of up to 5000 psi (350 bar). The plug features a valve hex size of 1\u00bc inches (31.8 mm) and should be installed with a torque between 150 to 160 lbf ft (203 to 217 Nm). It comes with a Viton seal kit identified by the cartridge number: 990023006. This cavity plug is part of the Series 3 line from Sun Hydraulics, known for its reliable performance in maintaining flow integrity under high-pressure conditions.
The Sun Hydraulics XPOAXXN (Material Number: XPOAXXN) is a versatile cavity plug designed for use in both four-port and six-port cavities. In four-port cavities such as T21A, T22A, T23A, and T24A, this plug effectively connects ports 1 and 2 while blocking ports 3 and 4. For six-port cavities like T61A, T62A, T63A, and T64A, it connects ports 1 through 4 and blocks ports 5 and 6. This product is suitable for applications requiring a maximum operating pressure of up to 5000 psi (350 bar). The plug features a valve hex size of 1\u00bc inches (31.8 mm) and should be installed with a torque between 150 to 160 lbf ft (203 to 217 Nm). It comes with a Viton seal kit identified by the cartridge number: 990023006. This cavity plug is part of the Series 3 line from Sun Hydraulics, known for its reliable performance in maintaining flow integrity under high-pressure conditions.
These cavity plugs can be used for both four-port and six-port cavities. When used in four-port cavities (T-21A, T-22A, T-23A and T-24A), ports 1 and 2 remain connected and ports 3 and 4 are blocked. When used in six-port cavities (T-61A, T-62A, T-63A and T-64A), ports 1, 2, 3 and 4 remain connected and ports 5 and 6 are blocked.
| Cavity | T-23A & T-63A |
| Series | 3 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-023-006 |
