SUN HYDRAULICS
YXC

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics YXC (Material Number: YXC) is a motor mount manifold designed specifically for use with Eaton CharLynn H and S series motors. This manifold features a cross port configuration and is constructed from 6061-T651 aluminum, known for its excellent corrosion resistance and strength. It includes four mounting holes with a diameter of 0.34 inches (8.6 mm) that go through the body, providing secure attachment to compatible motors. The manifold has two open cavities with T10A cavities and SAE 10 port sizes, facilitating efficient fluid control and motor protection. An essential aspect of using the YXC manifold is the requirement of a riser gage port adapter when paired with CharLynn S series motors. Compatible adapters include Sun models ZVQ NPT, WPA SAE, and WPB BSPP. It's crucial to consider the maximum system pressure when utilizing this manifold; although it is robustly built, manifolds made from aluminum are not rated for pressures exceeding 3000 psi (210 bar). This limitation ensures safe operation within specified parameters. The design of the YXC motor mount manifold enhances hydraulic system performance by providing reliable connections and efficient fluid flow management between components. Its construction supports various hydraulic applications where durability and corrosion resistance are critical factors, particularly in systems requiring precise control over motor operations.
