SUN HYDRAULICS
Z7F

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics Z7F (Material Number: Z7F) is a robust line mount manifold designed for hydraulic systems, featuring a 0.75 SAE C61 interface. This model is constructed from 6061T651 aluminum, known for its excellent corrosion resistance and strength, making it suitable for various demanding applications. The manifold includes direct mount capabilities through port 2 and offers a mounting hole diameter of 0.42 inches in metric models with a depth that extends through the material. It also has a mounting hole counterbore diameter of 0.68 inches and depth of 0.38 inches in metric models, with four mounting holes available to ensure secure installation. The Z7F manifold features an open cavity design (T2A) with port size options of 34 Code 61, providing flexibility in system integration and configuration. This product does not require anodizing due to the high corrosion resistance of the aluminum alloy used, which eliminates additional costs and logistical challenges associated with anodizing processes while maintaining structural integrity under pressure. When using this manifold, it is crucial to consider the maximum system pressure, as manifolds made from aluminum are not rated for pressures exceeding 3000 psi (210 bar). The design ensures efficient fluid handling while maintaining durability and performance across various hydraulic applications.
