SUN HYDRAULICS
ZAD
$251.87 USD
- SUN HYDRAULICS
- Material:ZAD
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZAD (Material Number: ZAD) is a robust line mount manifold designed for hydraulic systems, featuring a 1.50 SAE C61 interface that ensures compatibility with various system configurations. It is constructed from 6061T651 aluminum, known for its excellent corrosion resistance and strength, making it suitable for demanding environments. This manifold includes one open cavity (T-24A) and supports a port size of 1 1/2 Code 61, allowing it to accommodate high flow rates efficiently. The direct mount design facilitates easy integration into existing systems without requiring additional components or modifications. Notably, Sun Hydraulics has chosen not to anodize their aluminum bodies to maintain cost-effectiveness and avoid potential issues such as increased breakaway torque and reduced fatigue life associated with anodized surfaces. The ZAD manifold is engineered to operate at pressures up to 3000 psi (210 bar), ensuring reliable performance within these parameters.
The Sun Hydraulics ZAD (Material Number: ZAD) is a robust line mount manifold designed for hydraulic systems, featuring a 1.50 SAE C61 interface that ensures compatibility with various system configurations. It is constructed from 6061T651 aluminum, known for its excellent corrosion resistance and strength, making it suitable for demanding environments. This manifold includes one open cavity (T-24A) and supports a port size of 1 1/2 Code 61, allowing it to accommodate high flow rates efficiently. The direct mount design facilitates easy integration into existing systems without requiring additional components or modifications. Notably, Sun Hydraulics has chosen not to anodize their aluminum bodies to maintain cost-effectiveness and avoid potential issues such as increased breakaway torque and reduced fatigue life associated with anodized surfaces. The ZAD manifold is engineered to operate at pressures up to 3000 psi (210 bar), ensuring reliable performance within these parameters.
| Body Type | Line mountLine mount |
| Interface | 1.50 SAE C611.50 SAE C61 |
| Body Features | Direct mountDirect mount |
| Open Cavities | 11 |
| Cavity | T-24A |
| Port Size | 1 1/2" Code 611 1/2" Code 61 |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Standard Line Mount Manifolds for High Flow Valves
- Manufacturing Sun Cartridge Cavities
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
