SUN HYDRAULICS
ZAM

$51.92 USD

SUN HYDRAULICS
Material:ZAM
Summary:Manifold

Quantity in stock: 0

Note: Sales tax, and shipping will be calculated at checkout.

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZAM (Material Number: ZAM) is a line mount manifold designed for hydraulic systems, offering a direct mount capability with an open cavity configuration. This model features a 2-bolt interface specifically for fluid controls and accommodates a T11A cavity port size of SAE 6. Constructed from 6061T651 aluminum, this manifold is known for its corrosion resistance and durability, making it suitable for various hydraulic applications. The design does not include anodizing, which helps maintain the material's natural corrosion resistance and extends fatigue life by avoiding the brittleness that anodizing can introduce. This product is part of Sun Hydraulics' standard line mount manifolds tailored for high-flow valves and is compatible with their QuickDesign and SmartConnect tools, facilitating easy integration into hydraulic systems. It is crucial to note that while the aluminum construction offers excellent corrosion resistance, it limits the maximum system pressure to 3000 psi (210 bar). Therefore, careful consideration of system pressure requirements is essential when selecting this manifold to ensure optimal performance and safety in your hydraulic applications.

Description

Body Type	Line mountLine mount
Interface	Fluid Controls - 2 boltFluid Controls - 2 bolt
Body Features	Direct mountDirect mount
Open Cavities	11
Cavity	T-11A
Port Size	SAE 6SAE 6

Show FAQ

How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.
Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
