SUN HYDRAULICS
ZEV
$192.40 USD
- SUN HYDRAULICS
- Material:ZEV
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZEV (Material Number: ZEV) is a line mount manifold specifically designed to interface with a 1.25 SAE C61 connection. This product features a direct mount body type and is equipped with open cavities, specifically the T-23A cavity. The manifold includes one cavity and supports port sizes of 1 1/4 Code 61, making it suitable for various hydraulic applications that require efficient fluid management. Constructed from 6061-T651 aluminum, the ZEV manifold offers excellent corrosion resistance, which is crucial for maintaining durability in demanding environments. It is important to note that this aluminum material limits the maximum system pressure to 3000 psi (210 bar). The design of the ZEV manifold ensures compatibility with high flow valves and provides a robust solution for hydraulic systems requiring reliable performance.
The Sun Hydraulics ZEV (Material Number: ZEV) is a line mount manifold specifically designed to interface with a 1.25 SAE C61 connection. This product features a direct mount body type and is equipped with open cavities, specifically the T-23A cavity. The manifold includes one cavity and supports port sizes of 1 1/4 Code 61, making it suitable for various hydraulic applications that require efficient fluid management. Constructed from 6061-T651 aluminum, the ZEV manifold offers excellent corrosion resistance, which is crucial for maintaining durability in demanding environments. It is important to note that this aluminum material limits the maximum system pressure to 3000 psi (210 bar). The design of the ZEV manifold ensures compatibility with high flow valves and provides a robust solution for hydraulic systems requiring reliable performance.
| Body Type | Line mountLine mount |
| Interface | 1.25 SAE C611.25 SAE C61 |
| Body Features | Direct mountDirect mount |
| Open Cavities | 11 |
| Cavity | T-23A |
| Port Size | 1 1/4" Code 611 1/4" Code 61 |
Show FAQ
Additional Resources
- Standard Line Mount Manifolds for High Flow Valves
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Manufacturing Sun Cartridge Cavities
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
