SUN HYDRAULICS
ZLW

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZLW (Material Number: ZLW) is a robust subplate designed for hydraulic systems, compatible with the ISO 07 interface. This model features a P to T side port configuration and accommodates a single open cavity of type T-3A. The subplate is constructed from 6061-T651 aluminum, known for its excellent corrosion resistance and mechanical properties, making it suitable for various demanding environments. It includes two mounting holes with a diameter of 0.41 inches (10.4 mm) and depth through the entire plate, complemented by counterbores measuring 0.59 inches (15.0 mm) in diameter and 0.56 inches (14.2 mm) in depth to ensure secure installation. The ZLW model supports a port size of 3/4 NPTF, facilitating efficient fluid transfer within hydraulic systems while maintaining structural integrity up to a maximum pressure of 3000 psi (210 bar). This pressure rating ensures reliable performance in applications where consistent hydraulic flow is critical. Given its construction material and design features, this subplate offers durability without the need for anodizing, which can reduce fatigue life by inducing cracks during pressurization cycles. The Sun Hydraulics ZLW model is ideal for applications requiring dependable manifold solutions that maintain system integrity under varied operational conditions while providing ease of integration into existing hydraulic configurations.
