SUN HYDRAULICS
ZSA

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZSA (Material Number: ZSA) is a line mount manifold designed for high-flow hydraulic applications. It features a 0.75 SAE C61 interface and is constructed with a flange mount through port, allowing for efficient integration into hydraulic systems. The manifold accommodates four mounting holes with a diameter of 0.42 inches (10.7 mm for metric models), complemented by counterbore diameters of 0.69 inches (17.5 mm for metric models) and depths of 0.38 inches (9.7 mm for metric models). This design ensures secure attachment and stability in demanding environments. The ZSA model includes one open cavity, designated as T2A, and is equipped with SAE 12 port sizes, making it versatile for various hydraulic configurations. Constructed from 6061T651 aluminum, the manifold offers excellent corrosion resistance and durability while maintaining a lightweight profile suitable for diverse applications. It is crucial to consider the maximum system pressure when utilizing this manifold, as its aluminum construction limits its pressure rating to 3000 psi (210 bar), regardless of the specified port type or size. This specification ensures safe operation within recommended limits. Overall, the Sun Hydraulics ZSA manifold provides robust performance in high-flow hydraulic systems, offering reliable integration options with its precise engineering and durable materials.
