SUN HYDRAULICS
ZTF

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZTF (Material Number: ZTF) is a robust line mount manifold designed for high-flow hydraulic systems. This component features a direct mount, cross pilot body type and is engineered with precision to accommodate demanding applications. The manifold interface is standardized for compatibility with Sun's cartridge valves, ensuring seamless integration into existing systems. It includes 22 mounting holes with a diameter of 0.42 inches (10.7 mm) and a depth that goes through the entire body, providing secure and stable installation options. The mounting hole counterbore diameter measures 0.59 inches (15.0 mm) with a depth of 0.31 inches (8 mm), enhancing its adaptability to various setups. Constructed from 6061-T651 aluminum, this manifold offers excellent corrosion resistance and durability, making it suitable for challenging environments where exposure to elements might be a concern. The material choice also ensures that the manifold remains relatively strong while being cost-effective and easy to procure in various shapes and sizes. The Sun ZTF manifold accommodates open cavities in the T-2A configuration and features a port size of 1/2 NPTF, which supports efficient fluid transfer within hydraulic circuits. Its design does not include anodization, as the natural properties of the aluminum used provide sufficient corrosion resistance without compromising fatigue life or increasing manufacturing costs. This manifold is particularly suited for applications requiring reliable fluid distribution in high-pressure systems up to 3000 psi (210 bar). It serves as an essential component for industries relying on hydraulic power, offering versatility and performance where precise fluid control is paramount.
