SUN HYDRAULICS
LINE MOUNT BODY
ZTG

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZTG (Material Number: ZTG) is a line mount manifold designed for direct mounting with cross pilot capabilities. This component features a T2A cavity and is constructed for use with SAE 8 port sizes. The manifold includes 22 mounting holes, each with a diameter of .42 inches (10.7 mm) and a depth that allows for through-hole mounting. The counterbore diameter of these holes is .59 inches (15.0 mm), with a depth of .31 inches (8 mm). It has 11 open cavities, providing flexibility in hydraulic circuit design. The ZTG manifold is crafted from 6061T651 aluminum, known for its excellent corrosion resistance, making it suitable for various environmental conditions without the need for anodizing. The choice of material ensures durability while maintaining cost-effectiveness, though it limits the manifold's maximum pressure rating to 3000 psi (210 bar). This limitation should be carefully considered when integrating the manifold into hydraulic systems to prevent overpressure conditions. This Sun Hydraulics manifold is ideal for applications requiring high flow rates and efficient fluid distribution in hydraulic systems. Its robust design and construction allow it to be used in a wide range of settings where reliability and performance are critical. The manifold's compatibility with standard Sun cartridge cavities further enhances its versatility, enabling users to create customized hydraulic solutions that meet specific operational needs.
