SUN HYDRAULICS
ZTN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZTN (Material Number: ZTN) is a line mount body designed for hydraulic systems, featuring a direct mount with cross pilot capabilities. It is constructed from 6061T651 aluminum, known for its strong corrosion resistance, making it suitable for various environmental conditions. The manifold includes a mounting hole diameter of .34 inches (8.6 mm) and a c'bore diameter of .50 inches (12.7 mm), with the depth of the mounting hole being through and the c'bore depth at .25 inches (6.4 mm). With 22 mounting holes and 5 mounting face numbers, this product ensures secure installation and flexibility in hydraulic configurations. The ZTN model is built with an open cavity T11A and accommodates port size 3/8 NPTF, providing compatibility with standard hydraulic fittings. Its design does not include anodizing due to concerns about increased fatigue life reduction and other logistical challenges associated with the process. The manifold's maximum system pressure should not exceed 3000 psi (210 bar), as it is made from aluminum which limits its pressure rating despite the port type or size. This line mount manifold is ideal for applications requiring efficient fluid control without compromising on durability or performance under pressure constraints. Its robust construction ensures reliability in various hydraulic setups while maintaining cost-effectiveness due to the use of readily available materials that balance strength and machinability.
