SUN HYDRAULICS
ZTP
$83.79 USD
- SUN HYDRAULICS
- Material:ZTP
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZTP (Material Number: ZTP) is a specialized gasket mount manifold designed for hydraulic systems. It features a unique interface with all gasket ports, providing flexibility in various applications. The manifold is equipped with six mounting holes, each with a diameter of .28 inches (7.1 mm) and a through-depth configuration, allowing for secure attachment in hydraulic assemblies. The mounting holes also include a counterbore with a diameter of .41 inches (10.4 mm) and a depth of .22 inches (5.6 mm). This product includes one open cavity, designated as T11A, which can accommodate specific hydraulic components or configurations. This manifold's construction material plays a crucial role in its pressure capacity; it is important to note that manifolds made from aluminum are not suitable for pressures exceeding 3000 psi (210 bar), regardless of the port type or size specified. This makes it essential to consider the maximum system pressure when integrating this component into your hydraulic setup to ensure safety and functionality. The Sun Hydraulics ZTP is well-suited for applications requiring precise control and distribution of hydraulic fluid within complex systems where gasket mounting is preferred or necessary. Its design allows for efficient integration into existing systems while maintaining reliability under specified conditions.
The Sun Hydraulics ZTP (Material Number: ZTP) is a specialized gasket mount manifold designed for hydraulic systems. It features a unique interface with all gasket ports, providing flexibility in various applications. The manifold is equipped with six mounting holes, each with a diameter of .28 inches (7.1 mm) and a through-depth configuration, allowing for secure attachment in hydraulic assemblies. The mounting holes also include a counterbore with a diameter of .41 inches (10.4 mm) and a depth of .22 inches (5.6 mm). This product includes one open cavity, designated as T11A, which can accommodate specific hydraulic components or configurations. This manifold's construction material plays a crucial role in its pressure capacity; it is important to note that manifolds made from aluminum are not suitable for pressures exceeding 3000 psi (210 bar), regardless of the port type or size specified. This makes it essential to consider the maximum system pressure when integrating this component into your hydraulic setup to ensure safety and functionality. The Sun Hydraulics ZTP is well-suited for applications requiring precise control and distribution of hydraulic fluid within complex systems where gasket mounting is preferred or necessary. Its design allows for efficient integration into existing systems while maintaining reliability under specified conditions.
| Body Type | Gasket mountGasket mount |
| Interface | SpecialSpecial |
| Body Features | All gasket portsAll gasket ports |
| Mounting Hole Diameter | .28 in.7,1 mm |
| Mounting Hole Depth | ThroughThrough |
| Mounting Hole C'bore Diameter | .41 in.10,4 mm |
| Mounting Hole C'bore Depth | .22 in.5,6 mm |
| Mounting Hole Quantity | 66 |
| Open Cavities | 11 |
| Cavity | T-11A |
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
